Icom IC-761
| Type: |
Amateur HF Transceiver |
| Frequency Range: |
TX: 10-160 m + WARC
RX: 0.1-30 MHz |
| Modes: |
AM/FM/SSB/CW |
| RF Power output: |
10-100 W |
| Sensitivity: |
N/A |
| Selectivity: |
N/A |
| Image rejection: |
N/A |
| Voltage: |
13.8 VDC or Mains |
| Current Drain: |
RX: ? mA
TX: Max ? A |
| Aerial Input: |
50 ohms, SO-239 |
| Dimensions (W*H*D): |
424*150*390 mm |
| Weight: |
? |
| Manufactured: |
1987-19xx |
| Other: |
Built-in auto-AT. RS-232C |
| Related Documents: |
User Manual (5.5 MB) |
 |
